Magic Motorsport has released Flex software version 8.22.0.0 on September 25, 2026, introducing solderless Boot Glitch support for the Bosch MG1CS032 ECU found in Stellantis vehicles. Utilizing Korhex and Electromagnetic Fault Injection (EMFI) technology, technicians can access the SPC58 microprocessor without removing components or soldering the PCB.
Protocol Highlights & Performance
- Target ECU:Stellantis Bosch MG1CS032 (SPC58 MCU)
- Operation Mode:Boot Glitch (EMFI)
- Supported Operations:Read/Write/Checksum Internal Flash, Read/Write Internal EEPROM, Full Backup
- Connection Speed:~10 seconds
- Read Duration:~2 minutes 30 seconds
- Write Duration:~2 minutes
- Licensing Requirements: FLS0.20 Boot Glitch Master/Slave or Flex Full Master FLS0.5 M/Slave FLS0.5S
Guided Setup Protocol
Flex provides visual mask positioning instructions specific to the MG1CS032 ECU. Aligning the positioning mask as directed in the software allows operators to pinpoint the MCU contact area for fast, repeatable boot connection.
Some of the Vehicle Application List
- DS 3 (II) D34 (2023):2L PureTech 12v 99HP
- Jeep Avenger (I) J2 (2023):2L GSE 12v 100HP
- Opel Mokka (B) (2020):2L PureTech 12v 99HP
- Opel Corsa (F) (2023):2L PureTech 12v 99HP
- Peugeot 2008 (II) P24 (2023):2L PureTech 12v 99HP
Click here to check all supported vehicles
