Diagnose 2019 Kawasaki Z1000 All Systems: OBDSTAR MS80 or MS50?

Both OBDSTAR MS80 and MS50 are the new generation motorcycle diagnostic scanners. They have professional-level intelligent diagnosis, providing an unprecedented intelligent diagnosis and maintenance experience for motorcycle owners and repair shops.

Can they diagnose all systems for the 2019 Kawasaki Z1000? Which one is better to use?



OBDSTAR MS50 and MS80 both can test all systems for 2019 Kawasaki Z1000. Here are the related videos have been tested and verified 100% working by eobdtool.co.uk engineer.

OBDSTAR MS80 Test All System for 2019 Kawasaki Z1000

OBDSTAR MS50 Test All System for 2019 Kawasaki Z1000

From the videos above, we can see two OBDSTAR motorcycle diagnostic scanners can perform the same functions for Petrol injection and ABS systems using the same steps.

Main operation steps:
1.Use M041 EURO V connector and main cable to connect OBDSTAR MS50 or MS80 with the motorcycle-> start the motorcycle
M041 EURO V

2.Tap [DiagProgram] to enter MS80 or MS50 tablet main menu
3.Select [Moto Diag]-> [Asia]-> [KAWASAKI]-> [KAWASAKI V30.02]-> [Select from system]-> [Auto Scan]

4.Diagnose [Petrol injection] system and perform the following functions:
ECU information, Read fault codes, Erase fault codes, Read data flow, Freeze frames and Active test
obdstar ms50obdstar ms50 test

5.Then use M005 KAWASAKI to replace M041 EURO V to work with the main cable to connect OBDSTAR MS80 or MS50 with the motorcycle

6.Tap [Select from system]-> [Auto Scan]
7.Diagnose [ABS] system and perform the following functions:
ECU information, Read fault codes, Erase fault codes and Active test
obdstar ms50 pictureobdstar ms80 info

So, which one is better to purchase?

It depends on your budget and the motorcycle models you want to diagnose besides the 2019 Kawasaki Z1000.

OBDSTAR MS50 is cheaper than MS80.

The reason is that MS50 only supports the most common motorcycle diagnosis from Asia and Europe while MS80 adds more luxury motorcycle diagnosis from Asia, Europe and America. MS80 also provides IMMO key programming for Asian and European motorcycles but MS50 doesn’t support. Besides that, MS80 adds more adapters accordingly.

Check the comparison table to learn more similarities and differences between them. After that, make a decision depends on your actual need.

Item OBDSTAR MS80 OBDSTAR MS50
Price 2,203  423
Main menu Moto Diag, Other, TeamViewer, Personal Center, Settings, Support Center, Upgrade Moto Diag, Teamviewer, Personal Center, Settings, Support Center, Upgrade
Diag Cable High Quality,low price High Quality,low price
Main machine 8 inch android tablet 5 inch android tablet,OBD charge
Plastic Cover Industrial Design Industrial Design
Smart switch pin Highly integrated diagnostic connector Highly integrated diagnostic connector
Diag Connector OBD adapter, no need to disassemble OBD adapter, no need to disassemble
Operation System Android Android
Wifi one button click one button click
Language English and more local language English and more local language
Remote assistance Yes, engineer can assistant via remote control software Yes, engineer can assistant via remote control software
Function Code reading, code clearing, data flow, action test, setting, coding, etc. code reading, code clearing, data flow, action test, setting, coding, etc.
IMMO key programming EUROPE TRIUMPH
GILERA
PEUGEOT
PIAGGIO
DUCATI
VESPA
America HARLEY
Motorcycle Diagnosis Asia HONDA
KAWASAKI
KYMCO
SUZUKI
SYM
YAMAHA
MONTESA
PGO
HARTFORD
AEON
BENELLIDSK
Europe APRILIA
BENELLI
BMW
DUCATI
KTM
PIAGGIO
TRIUMPH
VESPA
MALAGUTI
GASGAS
GILERA
GUZZI
AGUSTA
DERBI
America HARLEY
INDIAN
VICTORY
BRP
OBD OBD-II OBD
Motorboat diagnosis Asia HONDABOAT
Accessories comparison
M001 Main Cable
M002 Power Cable
M002A  GND
M003A Multi functional jumper
M004 APRILIA/DUCATI/HONDA/
KTM/PIAGGIO/VESPA/YAMAHA
M005 KAWASAKI
M006 KAWASAKI
M012 SUZUKI
 M015A HONDA/HONDA MONTESA
M018 YAMAHA
M019 KTM
M021 AEON/BENELLI/BENELLI DSK
M026 SYM
M027 KYMCO/KAWASAKI
M028 PGO
M030 HARDFORD
M034 HARLEY-DAVIDSON
M037 DUCATI
M040 BMW
M041 EURO V
M042 INDIAN/VICTORY
M043  BRP
P001 IMMO KIT(Optional)
12V2A CHARGER
Support system 1. Comparable to the original factory
2. Full coverage of engine, ABS, traction control, airbag, instrumentation, power steering, alarm, chassis management, body, headlights, battery management, tire pressure, frame, anti-theft, suspension, radio, handle, and other systems
1. Comparable to the original factory
2. Full coverage of engine, ABS, traction control, airbag, instrumentation, power steering, alarm, chassis management, body, headlights, battery management, tire pressure, frame, anti-theft, suspension, radio, handle, and other systems
Advanced Function Comparable to the original factory (automatic scanning, automatic VIN recognition, control module programming and coding, ECU setting, instrument coding, tire pressure monitoring system, maintenance light reset, CO adjustment, idle speed adjustment, A/F value reset, ABS control unit Settings, EOL mode, transmission memory reset, clear computer memory, etc.) Comparable to the original factory (automatic scanning, automatic VIN recognition, control module programming and coding, ECU setting, instrument coding, tire pressure monitoring system, maintenance light reset, CO adjustment, idle speed adjustment, A/F value reset, ABS control unit Settings, EOL mode, transmission memory reset, clear computer memory, etc.)
Diagnostic connector location
Diagnostic connector Display
Technical Bulletin
Fault Guidance
Data Flow Text/ Waveform Diagram
Instrument Diagram
Any menu back
Interactive Circuit diagram
Components Description
